Cisco Catalyst 4500 Series Software Configuration Guide

9
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS
Chapter 9 Configuring Interfaces
Configuring MultiGigabit Ports on WS-X4748-12X48U+E
Configuring Module Modes on WS-X4748-12X48U+E
Note This mode command is applicable only to the selected module. When the mode command is changed for
a module, the operation of other modules on the switch is not impacted.
Note For the selected configuration to be applied, you must reset the module using the Switch#hw-module
module <slot> reset command.
To verify that the selected configuration is applied, enter the
Switch#show module command.
The following example shows how to configure an Ethernet mode on WS-X4748-12X48U+E:
Switch(config)#hw-module module 3 mode ?
1 Multigigabit lite :12 MultiGigabit ports(10:1 oversubscribed) and 36 1Gigabit ports
2 Multigigabit enhanced :12 MultiGigabit ports(5:1 oversubscribed) and 24 1Gigabit ports
3 Multigigabit performance :12 MultiGigabit ports(2.5:1 oversubscribed) only
For information about setting interface speeds to 2.5G, 5G or 10G, see Setting the Interface Speed, page 9-28.
Upgrading the Line Card FPGA Image on WS-X4748-12X48U+E
Beginning in Cisco IOS Release 3.7.1E, a new function to upgrade the line card FPGA on the WS-X4748-12X48U+E module
has been introduced to handle oversubscription on multigigabit ports. This upgrade capability allows feature updates or fixes
related to the line card FPGA on this module.
Note Before you begin, download the new FPGA image to the bootflash, to a TFTP server, or to a USB drive.
Caution Configuration for this module will be suspended during FPGA upgrade.The module is automatically
reset after the upgrade.
To upgrade the line card FPGA on WS-X4748-12X48U+E:
Table 9-3 Hardware and power supply not supported
Chassis Type Supervisor
• Cisco Catalyst 4507R-E
• Cisco Catalyst 4510R-E
• Supervisor Engine 6-E, Supervisor
Engine 6L-E and earlier.
Command Purpose
Step 1
Switch# configure terminal
Establishes global configuration mode.
Step 2
Switch(config)# hw-module module <slot> mode
<number>
Selects the configuration mode for the selected module.
