Cisco Catalyst 4500 Series Software Configuration Guide

35-6
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 35 Configuring Layer 3 Interfaces
Configuring Logical Layer 3 GRE Tunnel Interfaces
Configuring Logical Layer 3 GRE Tunnel Interfaces
Generic Routing Encapsulation (GRE) is a tunneling protocol used to encapsulate network layer
protocols inside virtual point-to-point links. A GRE tunnel only provides encapsulation and not
encryption.
Note Beginning in Cisco IOS XE Release 3.7.1E, GRE tunnels are supported on the hardware on
Catalyst 4500 series switches.
When GRE is configured without tunnel options, packets are hardware-switched. When GRE is
configured with tunnel options (such as key, checksum, etc.), packets are switched in the software.
Multicast routing is not supported on GRE tunnels, so PIM configuration is not supported on a GRE
tunnel interface.
To configure a GRE tunnel, perform this task:
This example shows how to configure the logical Layer 3 GRE tunnel interface tunnel 2:
Switch> enable
Switch# config term
Switch(config)# interface tunnel 2
Switch(config-if)# ipv6 address 1001:1::1/64
Switch(config-if)# ip address 100.1.1.1 255.255.255.0
Switch(config-if)# tunnel source 10.10.10.1
Switch(config-if)# tunnel destination 10.10.10.2
Switch(config-if)# tunnel mode gre ip
Switch(config-if)# end
Configuring Logical Layer 3 VLAN Interfaces
Note Before you can configure logical Layer 3 VLAN interfaces, you must create and configure the VLANs
on the switch, assign VLAN membership to the Layer 2 interfaces, enable IP routing if IP routing is
disabled, and specify an IP routing protocol.
Command Purpose
Step 1
Switch(config)# interface tunnel number
Enables tunneling on the interface.
Step 2
Switch(config-if)# ipv6 address ip_address
subnet_mask
Configures the IPv6 address and subnet mask.
Step 3
Switch(config-if)# ip address ip_address subnet_mask
Configures the IP address and IP subnet.
Step 4
Switch(config-if)# tunnel source {ip-address | type
number}
Configures the tunnel source.
Step 5
Switch(config-if)# tunnel destination {hostname |
ip-address}
Configures the tunnel destination.
Step 6
Switch(config-if)# tunnel mode gre ip
Configures the tunnel mode.
Step 7
Switch(config-if)# end
Exits configuration mode.
Step 8
Switch# copy running-config startup-config
Saves your configuration changes to NVRAM.
Step 9
Switch# show running-config interface tunnel number
Verifies the configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
