Page #935 background image
35-7
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 35 Configuring Layer 3 Interfaces
Configuring Logical Layer 3 VLAN Interfaces
To configure logical Layer 3 VLAN interfaces, perform this task:
This example shows how to configure the logical Layer 3 VLAN interface VLAN 2 and assign an IP
address:
Switch> enable
Switch# config term
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# vlan 2
Switch(config)# interface vlan 2
Switch(config-if)# ip address 10.1.1.1 255.255.255.248
Switch(config-if)# no shutdown
Switch(config-if)# end
This example shows how to use the show interfaces command to display the interface IP address
configuration and status of Layer 3 VLAN interface VLAN 2:
Switch# show interfaces vlan 2
Vlan2 is up, line protocol is down
Hardware is Ethernet SVI, address is 00D.588F.B604 (bia 00D.588F.B604)
Internet address is 172.20.52.106/29
MTU 1500 bytes, BW 1000000 Kbit, DLY 10 usec,
reliability 255/255, txload 1/255, rxload 1/255
Encapsulation ARPA, loopback not set
ARP type: ARPA, ARP Timeout 04:00:00
Last input never, output never, output hang never
Last clearing of "show interface" counters never
Input queue: 0/75/0/0 (size/max/drops/flushes); Total output drops: 0
Queueing strategy: fifo
Output queue: 0/40 (size/max)
5 minute input rate 0 bits/sec, 0 packets/sec
5 minute output rate 0 bits/sec, 0 packets/sec
0 packets input, 0 bytes, 0 no buffer
Received 0 broadcasts, 0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored
0 packets output, 0 bytes, 0 underruns
0 output errors, 0 interface resets
0 output buffer failures, 0 output buffers swapped out
Switch#
This example shows how to use the show running-config command to display the interface IP address
configuration of Layer 3 VLAN interface VLAN 2:
Switch# show running-config
Command Purpose
Step 1
Switch(config)# vlan vlan_ID
Creates the VLAN.
Step 2
Switch(config)# interface vlan vlan_ID
Selects an interface to configure.
Step 3
Switch(config-if)# ip address ip_address subnet_mask
Configures the IP address and IP subnet.
Step 4
Switch(config-if)# no shutdown
Enables the interface.
Step 5
Switch(config-if)# end
Exits configuration mode.
Step 6
Switch# copy running-config startup-config
Saves your configuration changes to NVRAM.
Step 7
Switch# show interfaces [type slot/interface]
Switch# show ip interfaces [type slot/interface]
Switch# show running-config interfaces [type
slot/interface]
Switch# show running-config interfaces vlan vlan_ID
Verifies the configuration.
