Chapter 75 Configuring Ethernet OAM and CFM
Configuring Ethernet CFM
Target domain: abc
Target MPID: 23
Target VLAN ID: 5
Request size (Padding portion): 0
Operation timeout (milliseconds): 5000
Class Of Service parameters: 0
Schedule:
Operation frequency (seconds): 60
Next Scheduled Start Time: Start Time already passed
Group Scheduled : FALSE
Randomly Scheduled : FALSE
Life (seconds): 3600
Entry Ageout (seconds): never
Recurring (Starting Everyday): FALSE
Status of entry (SNMP RowStatus): Active
Threshold (milliseconds): 5000
Distribution Statistics:
Number of statistic hours kept: 2
Number of statistic distribution buckets kept: 1
Statistic distribution interval (milliseconds): 20
Enhanced History:
History Statistics:
Number of history Lives kept: 0
Number of history Buckets kept: 15
History Filter Type: None
Switch#
Configuring an IP SLAs Operation with Endpoint Discovery
To use IP SLAs to automatically discover the CFM endpoints for a domain and VLAN ID, perform this
task. You can configure ping or jitter operations to the discovered endpoints.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# ip sla ethernet-monitor
operation-number
Begins configuration of an IP SLAs automatic Ethernet
operation, and enter IP SLAs Ethernet monitor
configuration mode.
