Cisco Catalyst 4500 Series Software Configuration Guide

75-22
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 75 Configuring Ethernet OAM and CFM
Configuring Ethernet CFM
Step 3
Switch(config-ip-sla-ethernet-monitor)# type
echo domain domain-name vlan vlan-id
[exclude-mpids mp-ids]
or
type jitter domain domain-name vlan vlan-id
[exclude-mpids mp-ids] [interval
interpacket-interval] [num-frames number-of
frames transmitted]
Configures the automatic Ethernet operation to create echo
(ping) or jitter operation and enters IP SLAs Ethernet echo
configuration mode.
• Enter type echo for a ping operation or type jitter for
a jitter operation.
• For mpid identifier, enter a maintenance endpoint
identifier. The range is 1 to 8191.
• For domain domain-name, enter the CFM domain
name.
• For vlan vlan-id, the VLAN range is from 1 to 4095.
• (Optional) Enter exclude-mpids mp-ids to exclude the
specified maintenance endpoint identifiers.
• (Optional—for jitter only) Enter the interval between
sending of jitter packets.
• (Optional—for jitter only) Enter the num-frames and
the number of frames to be sent.
Step 4
Switch(config-ip-sla-ethernet-echo)# cos
cos-value
(Optional) Sets a class of service value for the operation.
Step 5
Switch(config-ip-sla-ethernet-echo)# owner
owner-id
(Optional) Configures the SNMP owner of the IP SLAs
operation.
Step 6
Switch(config-ip-sla-ethernet-echo)#
request-data-size bytes
(Optional) Specifies the protocol data size for an IP SLAs
request packet. The range is from 0 to the maximum size
allowed by the protocol being used; the default is 66 bytes.
Step 7
Switch(config-ip-sla-ethernet-echo)# tag text
(Optional) Creates a user-specified identifier for an IP
SLAs operation.
Step 8
Switch(config-ip-sla-ethernet-echo)# threshold
milliseconds
(Optional) Specifies the upper threshold value in
milliseconds for calculating network monitoring statistics.
The range is 0 to 2147483647; the default is 5000.
Step 9
Switch(config-ip-sla-ethernet-echo)# timeout
milliseconds
(Optional) Specifies the amount of time in milliseconds
that the IP SLAs operation waits for a response from its
request packet. The range is 0 to 604800000; the default
value is 5000.
Step 10
Switch(config-ip-sla-ethernet-echo)# exit
Returns to global configuration mode.
Command Purpose
