Cisco Catalyst 4500 Series Software Configuration Guide

16-17
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 16 Configuring the Catalyst 4500 Series Switch with Cisco Network Assistant
Configuring Network Assistant in Community or Cluster Mode
!
interface GigabitEthernet1/13
!
interface GigabitEthernet1/14
!
interface GigabitEthernet1/15
!
interface GigabitEthernet1/16
!
interface GigabitEthernet1/17
!
interface GigabitEthernet1/18
!
interface GigabitEthernet1/19
!
interface GigabitEthernet1/20
!
interface Vlan1
no ip address
!
interface Vlan2
ip address 123.123.123.1 255.255.255.0
!
ip route 0.0.0.0 0.0.0.0 123.123.123.2
ip http server
ip http secure-server
ip http max-connections 16
ip http timeout-policy idle 180 life 180 requests 25
!
line con 0
password cna
login
stopbits 1
line vty 0 4
password cna
login
line vty 5 15
password cna
login
!
!
end
Switch#
Configuring Network Assistant in a Networked Switch in Cluster Mode
To configure Network Assistant on a networked switch in cluster mode, perform this task on the switch:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# enable password name
Enables password protection of configuration mode.
Step 3
Switch(config)# vtp domain name
Creates a VTP domain to manage VLANs and names.
Step 4
Switch(config)# cluster run
Launches the cluster on the cluster commander.
Step 5
Switch(config)# cluster enable cluster_name
Makes the switch the cluster commander.
Step 6
Switch(config)# vlan vlan_id
Creates a VLAN.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
