Cisco Catalyst 4500 Series - DAI Configuration Example

58-7
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 58 Configuring Dynamic ARP Inspection
Configuring Dynamic ARP Inspection
DAI Configuration Example
This example shows how to configure DAI on Switch A in VLAN 100. You would perform a similar
procedure on Switch B.
Switch A
SwitchA# show cdp neighbors
Capability Codes: R - Router, T - Trans Bridge, B - Source Route Bridge
S - Switch, H - Host, I - IGMP, r - Repeater, P - Phone
Device ID Local Intrfce Holdtme Capability Platform Port ID
SwitchB Gig 3/48 179 R S I WS-C4506 Gig 3/46
SwitchA# configure terminal
SwitchA(config)# ip arp inspection vlan 100
SwitchA(config)# interface g3/48
SwitchA(config-if)# ip arp inspection trust
SwitchA(config-if)# end
SwitchA# show ip arp inspection interfaces
Interface Trust State Rate (pps) Burst Interval
--------------- ----------- ---------- --------------
Gi1/1 Untrusted 15 1
Gi1/2 Untrusted 15 1
Step 5
Switch(config-if)# ip arp inspection trust
Configures the connection between the switches as trusted.
To return the interfaces to an untrusted state, use the
no ip arp inspection trust interface configuration command.
By default, all interfaces are untrusted.
The switch does not check ARP packets that it receives from the
other switch on the trusted interface. It forwards the packets.
For untrusted interfaces, the switch intercepts all ARP requests
and responses. It verifies that the intercepted packets have valid
IP-to-MAC address bindings before updating the local cache and
before forwarding the packet to the appropriate destination. The
switch drops invalid packets and logs them in the log buffer
according to the logging configuration specified with the
ip arp inspection vlan logging global configuration command.
For more information, see the “Configuring the Log Buffer”
section on page 58-14.
Step 6
Switch(config-if)# end
Returns to privileged EXEC mode.
Step 7
Switch# show ip arp inspection interfaces
Switch# show ip arp inspection vlan
vlan-range
Verifies the DAI configuration.
Step 8
Switch# show ip dhcp snooping binding
Verifies the DHCP bindings.
Step 9
Switch# show ip arp inspection statistics
vlan vlan-range
Checks the DAI statistics.
Step 10
Switch# copy running-config startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose
