Cisco Catalyst 4500 Series Software Configuration Guide

66-18
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 66 Configuring SPAN and RSPAN
Configuring RSPAN
This example shows how to clear any existing RSPAN configuration for session 1, configure RSPAN
session 1 to monitor multiple source interfaces, and configure the destination RSPAN VLAN.
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# no monitor session 1
Switch(config)# monitor session 1 source interface fastEthernet3/10 tx
Switch(config)# monitor session 1 source interface fastEthernet3/2 rx
Switch(config)# monitor session 1 source interface fastEthernet3/3 rx
Switch(config)# monitor session 1 source interface port-channel 102 rx
Switch(config)# monitor session 1 destination remote vlan 901
Switch(config)# end
Creating an RSPAN Destination Session
To create an RSPAN destination session and to specify the source RSPAN VLAN and the destination
port, perform this task:
Step 7
Switch(config)# monitor session
session_number destination remote vlan
vlan-ID
Specifies the RSPAN session and the destination remote VLAN.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
For vlan-ID, specifies the RSPAN VLAN to carry the monitored
traffic to the destination port.
Step 8
Switch(config)# end
Returns to privileged EXEC mode.
Step 9
Switch# show monitor [session
session_number]
Verifies your entries.
Step 10
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# monitor session
session_number source remote vlan
vlan-ID
Specifies the RSPAN session and the source RSPAN VLAN.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
For vlan-ID, specifies the source RSPAN VLAN to monitor.
