Cisco Catalyst 4500 Series Software Configuration Guide

47-17
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 47 Configuring Private VLANs
Configuring PVLANs
Switch# configure terminal
Switch(config)# vlan 202
Switch(config-vlan)# private-vlan association 303-307,309,440
Switch(config-vlan)# end
Switch# show vlan private-vlan
Primary Secondary Type Interfaces
------- --------- ----------------- ------------------------------------------
202 303 community
202 304 community
202 305 community
202 306 community
202 307 community
202 309 community
202 440 isolated
202 550 twoway-community
202 551 twoway-community
202 552 twoway-community
308 community
Note The secondary VLAN 308 has no associated primary VLAN.
Configuring a Layer 2 Interface as a PVLAN Promiscuous Port
To configure a Layer 2 interface as a PVLAN promiscuous port, perform this task:
Note The maximum number of unique PVLAN pairs supported by the switchport private-vlan mapping
command is 1000.
When you configure a Layer 2 interface as a PVLAN promiscuous port, note the following:
• The secondary_vlan_list parameter cannot contain spaces. It can contain multiple comma-separated
items. Each item can be a single PVLAN ID or a hyphenated range of PVLAN IDs.
• Enter a secondary_vlan_list or use the add keyword with a secondary_vlan_list to map the
secondary VLANs to the PVLAN promiscuous port.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# interface {fastethernet |
gigabitethernet | tengigabitethernet} slot/port
Specifies the LAN interface to configure.
Step 3
Switch(config-if)# switchport mode private-vlan
{host | promiscuous | trunk promiscuous | trunk
[secondary]}
Configures a Layer 2 interface as a PVLAN promiscuous
port.
Step 4
Switch(config-if)# [no] switchport private-vlan
mapping [trunk] primary_vlan_ID
{secondary_vlan_list | add secondary_vlan_list |
remove secondary_vlan_list}
Maps the PVLAN promiscuous port to a primary VLAN
and to selected secondary VLANs.
Step 5
Switch(config-if)# end
Exits configuration mode.
Step 6
Switch# show interfaces {fastethernet |
gigabitethernet | tengigabitethernet} slot/port
switchport
Verifies the configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
