Cisco Catalyst 4500 Series Software Configuration Guide

CHAPTER
72-1
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
72
Configuring SNMP
This chapter describes how to configure the Simple Network Management Protocol (SNMP) on the
Catalyst 4500 series switch.
This chapter consists of these sections:
• About SNMP, page 72-1
• Configuring SNMP, page 72-5
• Displaying SNMP Status, page 72-16
Note For complete syntax and usage information for the switch commands used in this chapter, see the
Cisco IOS Command Reference Guides for the Catalyst 4500 Series Switch.
If a command is not in the Cisco Catalyst 4500 Series Switch Command Reference , you can locate it in
the Cisco IOS Master Command List, All Releases.
About SNMP
SNMP is an application-layer protocol that provides a message format for communication between
managers and agents. The SNMP system consists of an SNMP manager, an SNMP agent, and a MIB.
The SNMP manager can be part of a network management system (NMS) such as CiscoWorks. The agent
and MIB reside on the switch. To configure SNMP on the switch, you define the relationship between
the manager and the agent.
The SNMP agent contains MIB variables whose values the SNMP manager can request or change. A
manager can get a value from an agent or store a value into the agent. The agent gathers data from the
MIB, the repository for information about device parameters and network data. The agent can also
respond to a manager’s requests to get or set data.
An agent can send unsolicited traps to the manager. Traps are messages alerting the SNMP manager to
a condition on the network. Traps can mean improper user authentication, restarts, link status (up or
down), MAC address tracking, closing of a Transmission Control Protocol (TCP) connection, loss of
connection to a neighbor, or other significant events.
This section includes information about these topics:
• SNMP Versions, page 72-2
• SNMP Manager Functions, page 72-3
• SNMP Agent Functions, page 72-4

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
