Cisco Catalyst 4500 Series Software Configuration Guide

75-18
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 75 Configuring Ethernet OAM and CFM
Configuring Ethernet CFM
Use the no form of each command to remove a configuration or to return to the default settings.
The following example illustrates how to configure Ethernet CFM fault alarms:
Switch(config)# ethernet cfm alarm notification remote-error-xcon
Switch(config)# ethernet cfm logging alarm ieee
Switch(config)# interface gigabitethernet1/2
Switch(config-if)# ethernet cfm mep domain abc mpid 222 vlan 5
Switch(config-if-ecfm-mep)# alarm notification mac-remote-error-xcon
Switch(config-if)# end
Configuring IP SLAs CFM Operation
You can manually configure an IP SLA’s Ethernet ping or jitter echo operation, or you can configure
IP SLAs Ethernet operation with endpoint discovery. You can also configure multiple operation
scheduling. For accurate one-way delay statistics, the clocks on the endpoint switches must be
synchronized. You can configure the endpoint switches with Network Time Protocol (NTP) so that the
switches are synchronized to the same clock source.
For detailed information about configuring IP SLAs Ethernet operations, see the Cisco IOS IP SLAs for
Metro-Ethernet feature module at this URL:
http://www.cisco.com/en/US/docs/ios-xml/ios/ipsla/configuration/15-1s/Configuring_Cisco_IOS_IP_S
LAs_for_Metro-Ethernet.html
and
http://www.cisco.com/en/US/docs/ios-xml/ios/ipsla/configuration/xe-2/Configuring_IP_SLAs_for_Me
tro-Ethernet.html
For detailed information about IP SLAs operations, see the Cisco IOS IP SLAs Configuration Guide,
Release 12.4T at this URL:
http://www.cisco.com/en/US/products/ps6441/products_installation_and_configuration_guides_list.ht
ml
For detailed information about IP SLAs commands, see the command reference at this URL:
http://www.cisco.com/en/US/docs/ios/ipsla/command/reference/sla_book.html
This section includes these procedures:
• Manually Configuring an IP SLAs CFM Probe or Jitter Operation, page 75-19
• Configuring an IP SLAs Operation with Endpoint Discovery, page 75-21
Step 10
end
Returns to privileged EXEC mode.
Step 11
show running-config
Verifies your entries.
Step 12
copy running-config startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
