Cisco Catalyst 4500 Series Software Configuration Guide

41-7
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 41 Configuring Campus Fabric
Multicast Using Campus Fabric Overlay
exit
!
exit
!
loc-reach-algorithm lsb-reports ignore
disable-ttl-propagate
ipv4 sgt
ipv4 use-petr 192.168.1.6 priority 10 weight 10
ipv4 itr map-resolver 192.168.1.4
ipv4 itr map-resolver 192.168.1.5
ipv4 itr
ipv4 etr map-server 192.168.1.4 key example-key1
ipv4 etr map-server 192.168.1.5 key example-key2
ipv4 etr
exit
Multicast Using Campus Fabric Overlay
You can use Campus Fabric overlay to carry multicast traffic over core networks that do not have native
multicast capabilities. Campus Fabric overlay allows unicast transport of multicast traffic with head-end
replication at the edge device.
Note Only Protocol Independent Multicast (PIM) Sparse Mode and PIM Source Specific Multicast (SSM) are
supported in Campus Fabric. Dense mode is not supported in Campus Fabric.
Configuring Multicast PIM Sparse Mode in Campus Fabric
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# ip
multicast-routing
Enables IP multicast routing.
Step 3
Switch(config)# ip pim rp-address
rp address
Statically configures the address of a Protocol Independent Multicast
(PIM) rendezvous point (RP) for multicast groups.
Step 4
Switch(config)# interface LISP
interface number
Specifies the LISP interface and the subinterface on which to enable
Protocol Independent Multicast (PIM) sparse mode.
Step 5
Switch(config-if)# ip pim
sparse-mode
Enables Protocol Independent Multicast (PIM) on the interface for
sparse-mode operation.
Step 6
Switch(config-if)# exit
Exits interface configuration mode and enters global configuration mode.
Step 7
Switch(config)# interface interface
type interface number
Configures the interface facing the endpoint, and enters interface
configuration mode.
Step 8
Switch(config-if)# ip pim
sparse-mode
Enables Protocol Independent Multicast (PIM) on interface for
sparse-mode operation.
Step 9
Switch(config-if)# end
Ends the current configuration session and returns to privileged EXEC
mode.
