Page #465 background imageLoading...
Page #465 background image
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS
Chapter 9 Configuring Interfaces
Selecting the Uplink Port on a Supervisor Engine 7L-E
The no form of the hw-module daughtercard disable command enables the daughter card.
To enable Sup7-E mode on Supervisor Engine 8-E, when the daughter card is disabled, enter the following commands:
The no form of the hw-module uplink mode 40Gig command restores the default Supervisor Engine 8-E mode.
Selecting the Uplink Port on a Supervisor Engine 7L-E
With Cisco IOS Release 15.0(2)SG, the SFP+/SFP uplink modes on Supervisor Engine 7L-E (WS-X45-SUP-7L-E) have
changed. The number of uplink ports now depends on the supervisor engine mode (single or redundant) and the uplink mode
configuration (1-Gigabit or 10-Gigabit). To configure the uplink mode, use the hw-module uplink select [gigabitethernet/
tengigabitethernet] command, as follows:
Switch(config)# hw-module uplink select?
gigabitethernet Select the gigabit uplinks
tengigabitethernet Select the 10G uplinks
Note Supervisor Engine 7L-E is not supported on a ten-slot chassis. USB device and SD card support is
applicable to Supervisor Engine 7-E and Supervisor Engine 8-E only.
Note Supervisor Engine 8-E is supported on a 10-slot chassis.
Single Supervisor Mode
In single supervisor mode, WS-X45-SUP-7L-E supports the uplink configuration of at most either two 10-Gigabit or four
1-Gigabit ports (Table 9-5).
Command Purpose
Step 1
switch (config)# hw-module daughtercard disable
Disables the daughter card on the switch.
Note This command is not available in Bundle
Boot mode.
Step 2
Save the configuration and perform a power cycle or reload
the supervisor.
Then enter:
switch# sh hw-module daughtercard
Displays updated daughter card details for
Supervisor Engine 8-E, after the supervisor engine
is reloaded.
Command Purpose
Step 1
switch (config)# hw-module uplink mode 40Gig
Configures the uplink mode to 40GB.
Step 2
Save the configuration and perform a power cycle or reload
the supervisor.
Then enter:
switch# show run | incl uplink
Displays the uplink configuration for Supervisor
Engine 8-E.
