Cisco Catalyst 4500 Series Software Configuration Guide

48-15
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 48 Configuring MACsec Encryption
Understanding MKA MACsec with EAP-TLS
Ensure that you enroll both the participating devices and the RADIUS server to the PKI infrastructure.
For more information on PKI configuration, see the Public Key Infrastructure Configuration Guide.
Configuring MKA MACsec Using EAP-TLS
To configure MACsec with MKA on point-to-point links, perform these tasks:
• Configure an Authentication Policy
• Configure EAP-TLS Profiles and IEEE 802.1x Credentials
• Configure 802.1x and MKA MACsec using EAP-TLS on Interfaces
Configuring EAP-TLS and 802.1x Credentials
To configure EAP-TLS and 802.1x credentials, perform the following task:
Step 8
exit
Exits ca-trustpoint configuration mode and returns to global configuration
mode.
Step 9
crypto pki authenticate name
Retrieves the CA certificate and authenticates it.
Step 10
crypto pki enroll name
Generates certificate request and displays the request for copying and
pasting into the certificate server.
Enter enrollment information when you are prompted. For example,
specify whether to include the device FQDN and IP address in the
certificate request.
You are also given the choice about displaying the certificate request to
the console terminal.
The base-64 encoded certificate with or without PEM headers as
requested is displayed.
Step 11
crypto pki import name certificate
Imports a certificate via TFTP at the console terminal, which retrieves the
granted certificate.
The device attempts to retrieve the granted certificate via TFTP using the
same filename used to send the request, except the extension is changed
from “.req” to “.crt”. For usage key certificates, the extensions “-sign.crt”
and “-encr.crt” are used.
The device parses the received files, verifies the certificates, and inserts
the certificates into the internal certificate database on the router.
Note Some CAs ignore the usage key information in the certificate
request and issue general purpose usage certificates. If your CA
ignores the usage key information in the certificate request, only
import the general purpose certificate. The device will not use one
of the two key pairs generated.
Step 12
exit
Exits Global Configuration mode.
Step 13
show crypto pki certificate
trustpoint name
Displays information about the certificate for the trust point.
Step 14
copy running-config startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose
