Cisco Catalyst 4500 Series Software Configuration Guide

29-8
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 29 Configuring IPv6 Multicast Listener Discovery Snooping
Configuring IPv6 MLD Snooping
To remove a multicast router port from the VLAN, use the no ipv6 mld snooping vlan vlan-id mrouter
interface interface-id global configuration command.
This example shows how to add a multicast router port to VLAN 200:
Switch# configure terminal
Switch(config)# ipv6 mld snooping vlan 200 mrouter interface gigabitethernet1/
0/2
Switch(config)# exit
Enabling MLD Immediate Leave
When you enable MLDv1 Immediate Leave, the switch immediately removes a port from a multicast
group when it detects an MLD Done message on that port. You should only use the Immediate Leave
feature when there is a single receiver present on every port in the VLAN. When multiple clients exist
for a multicast group on the same port, do not enable Immediate-Leave in a VLAN.
To enable MLDv1 Immediate Leave, perform this task:
To disable MLD Immediate Leave on a VLAN, use the no ipv6 mld snooping vlan vlan-id
immediate-leave global configuration command.
This example shows how to enable MLD Immediate Leave on VLAN 130:
Switch# configure terminal
Switch(config)# ipv6 mld snooping vlan 130 immediate-leave
Switch(config)# exit
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# ipv6 mld snooping vlan
vlan-id mrouter interface interface-id
Specifies the multicast router VLAN ID, and specify the
interface to the multicast router.
• The VLAN ID range is 1 to 1001 and 1006 to 4094.
• The interface can be a physical interface or a port channel.
The port-channel range is 1 to 64.
Step 3
Switch(config)# end
Returns to privileged EXEC mode.
Step 4
Switch# show ipv6 mld snooping mrouter
[vlan vlan-id]
Verifies that IPv6 MLD snooping is enabled on the VLAN
interface.
Step 5
Switch# copy running-config startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# ipv6 mld snooping
vlan vlan-id immediate-leave
Enables MLD Immediate Leave on the VLAN interface.
Step 3
Switch(config)# end
Returns to privileged EXEC mode.
Step 4
Switch# show ipv6 mld snooping vlan
vlan-id
Verifies that Immediate Leave is enabled on the VLAN interface.
Step 5
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
