Chapter 30 Configuring 802.1Q Tunneling, VLAN Mapping, and Layer 2 Protocol Tunneling
Configuring VLAN Mapping
switchport trunk native vlan 40
switchport mode trunk
switchport vlan mapping 10 20
spanning-tree bpdufilter enable
end
• If you need to merge CVLAN and SVLAN spanning tree topology, you do not need to configure
spanning-tree bpdufilter enable.
• To ensure consistent operation, do not use a native VLAN for translation.
Configuring VLAN Mapping
The following procedures show how to configure each type of VLAN mapping on trunk ports. To verify
your configuration, enter either the show interfaces interface-id vlan mapping or the
show vlan mapping privileged EXEC command. See the “Monitoring and Maintaining Tunneling
Status” section on page 30-23 for the syntax of these commands. For more information about all
commands in this section, see the Catalyst 4500 Series Switch Software Command Reference for this
release.
The following VLAN mapping types are discussed:
• One-to-One Mapping, page 30-10
• Traditional Q-in-Q on a Trunk Port, page 30-11
• Selective Q-in-Q on a Trunk Port, page 30-12
One-to-One Mapping
To configure one-to-one VLAN mapping to map a customer VLAN ID to a service-provider VLAN ID,
perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# interface
interface-id
Enters interface configuration mode for the interface connected to the
service-provider network. You can enter a physical interface or an
EtherChannel port channel.
Step 3
Switch(config-if)# switchport mode
trunk
Configures the interface as a trunk port.
Step 4
Switch(config-if)# switchport vlan
mapping vlan-id translated-id
Enters the VLAN IDs to be mapped:
• vlan-id—the customer VLAN ID (C-VLAN) entering the switch
from the customer network. The range is from 1 to 4094.
• translated-id—the assigned service-provider VLAN ID (S-VLAN).
The range is from 1 to 4094.
Note Packets with unconfigured vlan_ids are dropped.
Step 5
Switch# end
Returns to privileged EXEC mode.
Step 6
Switch# show vlan mapping
Verifies the configuration.
Step 7
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
