Page #996 background imageLoading...
Page #996 background image
38-24
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 38 Configuring IP Multicast
Monitoring and Maintaining IP Multicast Routing
Displaying System and Network Statistics
You can display specific statistics, such as the contents of IP routing tables and databases. Information
provided can be used to determine resource utilization and solve network problems. You can also display
information about node reachability and discover the routing path your device’s packets are taking using
the network.
To display various routing statistics, enter any of these commands:
Displaying the Multicast Routing Table
The following is sample output from the show ip mroute command for a router operating in dense mode.
This command displays the contents of the IP multicast FIB table for the multicast group named
cbone-audio.
Switch# show ip mroute cbone-audio
IP Multicast Routing Table
Flags: D - Dense, S - Sparse, C - Connected, L - Local, P - Pruned
R - RP-bit set, F - Register flag, T - SPT-bit set
Timers: Uptime/Expires
Interface state: Interface, Next-Hop, State/Mode
(*, 224.0.255.1), uptime 0:57:31, expires 0:02:59, RP is 0.0.0.0, flags: DC
Incoming interface: Null, RPF neighbor 0.0.0.0, Dvmrp
Outgoing interface list:
Ethernet0, Forward/Dense, 0:57:31/0:02:52
Tunnel0, Forward/Dense, 0:56:55/0:01:28
(198.92.37.100/32, 224.0.255.1), uptime 20:20:00, expires 0:02:55, flags: C
Incoming interface: Tunnel0, RPF neighbor 10.20.37.33, Dvmrp
Outgoing interface list:
Ethernet0, Forward/Dense, 20:20:00/0:02:52
The following is sample output from the show ip mroute command for a router operating in sparse
mode:
Switch# show ip mroute
IP Multicast Routing Table
Flags: D - Dense, S - Sparse, C - Connected, L - Local, P - Pruned
R - RP-bit set, F - Register flag, T - SPT-bit set
Timers: Uptime/Expires
Interface state: Interface, Next-Hop, State/Mode
(*, 224.0.255.3), uptime 5:29:15, RP is 198.92.37.2, flags: SC
Command Purpose
Switch# ping [group-name | group-address]
Sends an ICMP Echo Request to a multicast
group address.
Switch# show ip mroute [hostname |
group_number]
Displays the contents of the IP multicast routing
table.
Switch# show ip pim interface [type number]
[count]
Displays information about interfaces configured
for PIM.
Switch# show ip interface
Displays PIM information for all interfaces.
