Cisco Catalyst 4500 Series Software Configuration Guide

38-22
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 38 Configuring IP Multicast
Configuring IP Multicast Routing
This example shows how to configure a single-static RP:
Switch> enable
Switch# configure terminal
Switch(config)# ip multicast-routing
Switch(config)# interface ethernet 1
Switch(config-if)# ip pim sparse-mode
Switch(config-if)# exit
Switch(config)# ip pim rp-address 192.168.0.0
Switch(config)# end
Switch# show ip pim rp mapping
Switch# show ip igmp groups
Switch# show ip mroute cbone-audio
Load Splitting of IP Multicast Traffic
Note This feature is only supported on Enterprise Services. It is not supported on IP Base and LAN Base.
If two or more equal-cost paths from a source are available, unicast traffic is load split across those paths.
However, by default, multicast traffic is not load split across multiple equal-cost paths. In general,
multicast traffic flows down from the reverse path forwarding (RPF) neighbor. According to the Protocol
Independent Multicast (PIM) specifications, this neighbor must have the highest IP address if more than
one neighbor has the same metric.
Use the ip multicast multipath command to enable load splitting of IP multicast traffic across multiple
equal-cost paths.
Note The ip multicast multipath command does not work with bidirectional Protocol Independent Multicast
(PIM).
Step 10
Switch# show ip pim rp [mapping] [rp-address]
(Optional) Displays RPs known in the network and shows
how the router learned about each RP.
Step 11
Switch# show ip igmp groups [group-name |
group-address | interface-type
interface-number] [detail]
(Optional) Displays the multicast groups having receivers
that are directly connected to the router and that were
learned through IGMP.
• A receiver must be active on the network at the time
that this command is issued to ensure that receiver
information is present on the resulting display.
Step 12
Switch# show ip mroute [group-address |
group-name] [source-address | source-name]
[interface-type interface-number] [summary]
[count] [active kbps]
(Optional) Displays the contents of the IP multicast routing
(mroute) table.
Command or Action Purpose

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
