62-25
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 62 Configuring Network Security with ACLs
Configuring VLAN Maps
Example 4
In this example, the VLAN map is configured to drop all packets (IP and non-IP). By applying access
lists tcp-match and good-hosts, the VLAN map is configured to do the following:
• Forward all TCP packets
• Forward MAC packets from hosts 0000.0c00.0111 and 0000.0c00.0211
• Drop all other IP packets
• Drop all other MAC packets
Switch(config)# vlan access-map drop-all-default 10
Switch(config-access-map)# match ip address tcp-match
Switch(config-access-map)# action forward
Switch(config-access-map)# exit
Switch(config)# vlan access-map drop-all-default 20
Switch(config-access-map)# match mac address good-hosts
Switch(config-access-map)# action forward
Applying a VLAN Map to a VLAN
To apply a VLAN map to one or more VLANs, perform this task:
Note You cannot apply a VLAN map to a VLAN on a switch that has ACLs applied to Layer 2 interfaces (port
ACLs).
This example shows how to apply VLAN map 1 to VLANs 20 through 22:
Switch(config)# vlan filter map 1 vlan-list 20-22
Using VLAN Maps in Your Network
Figure 62-3 shows a typical wiring closet configuration. Host X and Host Y are in different VLANs,
connected to wiring closet switches A and C. Traffic moving from Host X to Host Y is routed by Switch
B. Access to traffic moving from Host X to Host Y can be controlled at the entry point of Switch A. In
the following configuration, the switch can support a VLAN map and a QoS classification ACL.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# vlan filter mapname
vlan-list list
Applies the VLAN map to one or more VLAN IDs.
The list can be a single VLAN ID (22), a consecutive list (10-22), or
a string of VLAN IDs (12, 22, 30). Spaces around comma, and dash,
are optional.
Step 3
Switch(config)# show running-config
Displays the access list configuration.
Step 4
Switch(config)# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
