Cisco Catalyst 4500 Series Software Configuration Guide

27-8
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 27 Configuring EtherChannel and Link State Tracking
Configuring EtherChannel
These sections describe Layer 3 EtherChannel configuration:
• Creating Port Channel Logical Interfaces, page 27-8
• Configuring Physical Interfaces as Layer 3 EtherChannels, page 27-8
Creating Port Channel Logical Interfaces
Note To move an IP address from a physical interface to an EtherChannel, you must delete the IP address from
the physical interface before configuring it on the port channel interface.
To create a port channel interface for a Layer 3 EtherChannel, perform this task:
This example shows how to create port channel interface 1:
Switch# configure terminal
Switch(config)# interface port-channel 1
Switch(config-if)# ip address 172.32.52.10 255.255.255.0
Switch(config-if)# end
This example shows how to verify the configuration of port channel interface 1:
Switch# show running-config interface port-channel 1
Building configuration...
Current configuration:
!
interface Port-channel1
ip address 172.32.52.10 255.255.255.0
no ip directed-broadcast
end
Switch#
Configuring Physical Interfaces as Layer 3 EtherChannels
To configure physical interfaces as Layer 3 EtherChannels, perform this task for each interface:
Command Purpose
Step 1
Switch(config)# interface port-channel
port_channel_number
Creates the port channel interface. The value for
port_channel_number can range from 1 to 254 for a
standalone switch, and from 1 to 256 for switches in VSS
mode.
Step 2
Switch(config-if)# ip address ip_address mask
Assigns an IP address and subnet mask to the
EtherChannel.
Step 3
Switch(config-if)# end
Exits configuration mode.
Step 4
Switch# show running-config interface
port-channel port_channel_number
Verifies the configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
