Cisco Catalyst 4500 Series Software Configuration Guide

CHAPTER
17-1
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
17
Configuring VLANs, VTP, and VMPS
This chapter describes VLANs on Catalyst 4500 series switches. It also describes how to enable the
VLAN Trunking Protocol (VTP) and to configure the Catalyst 4500 series switch as a VMPS client.
This chapter includes the following major sections:
• VLANs, page 17-1
• VLAN Trunking Protocol, page 17-7
• VLAN Membership Policy Server, page 17-20
Note For complete syntax and usage information for the switch commands used in this chapter, see the
Cisco IOS Command Reference Guides for the Catalyst 4500 Series Switch.
If a command is not in the Cisco Catalyst 4500 Series Switch Command Reference , you can locate it in
the Cisco IOS Master Command List, All Releases.
VLANs
This section includes the following major subsections:
• About VLANs, page 17-1
• VLAN Configuration Guidelines and Restrictions, page 17-3
• VLAN Default Configuration, page 17-4
• Configuring VLANs, page 17-5
About VLANs
A VLAN is a group of devices on one or more LANs that are configured to communicate as if they were
attached to the same wire, when in fact they are located on a number of different LAN segments. Because
VLANs are based on logical instead of physical connections, they are extremely flexible.
Note VTP version 3 updates do not pass through promiscuous trunk ports.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
