Cisco Catalyst 4500 Series Software Configuration Guide

28-34
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 28 Configuring IGMP Snooping and Filtering, and MVR
Displaying IGMP Filtering Configuration
interface FastEthernet2/12
no ip address
shutdown
snmp trap link-status
ip igmp max-groups 25
ip igmp filter 4
end
Displaying IGMP Filtering Configuration
You can display IGMP profile and maximum group configuration for all interfaces on the switch or for
a specified interface.
To display IGMP profiles, perform this task:
To display interface configuration, perform this task:
This is an example of the show ip igmp profile privileged EXEC command when no profile number is
entered. All profiles defined on the switch are displayed.
Switch# show ip igmp profile
IGMP Profile 3
range 230.9.9.0 230.9.9.0
IGMP Profile 4
permit
range 229.9.9.0 229.255.255.255
This is an example of the show running-config privileged EXEC command when an interface is
specified with IGMP maximum groups configured and IGMP profile 4 has been applied to the interface:
Switch# show running-config interface fastethernet2/12
Building configuration...
Current configuration : 123 bytes
!
interface FastEthernet2/12
no ip address
shutdown
snmp trap link-status
ip igmp max-groups 25
ip igmp filter 4
end
Command Purpose
Switch# show ip igmp profile [profile number]
Displays the specified IGMP profile or all IGMP profiles defined
on the switch.
Command Purpose
Switch# show running-configuration [interface
interface-id
]
Displays the configuration of the specified interface or all
interfaces on the switch, including (if configured) the maximum
number of IGMP groups to which an interface can belong and the
IGMP profile applied to the interface.
