Chapter 66 Configuring SPAN and RSPAN
Configuring RSPAN
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# no monitor session 2
Switch(config)# monitor session 2 source vlan 1 - 3 rx
Switch(config)# monitor session 2 destination remote vlan 902
Switch(config)# monitor session 2 source vlan 10 rx
Switch(config)# end
Specifying VLANs to Filter
To limit RSPAN source traffic to specific VLANs, perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# no monitor session
{session_number | all | local |
remote}
Clears any existing SPAN configuration for the session.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
Specify all to remove all SPAN sessions, local to remove all local
sessions, or remote to remove all remote SPAN sessions.
Step 3
Switch(config)# [no] monitor session
{session_number} {source {interface
interface_list | {vlan vlan_IDs | cpu
[queue queue_ids]} [rx | tx | both]
Specifies the characteristics of the source port (monitored port) and
RSPAN session.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
For interface-list, specifies the source port to monitor. The interface
specified must already be configured as a trunk port.
For vlan-IDs, the range is 1 to 4094; do not enter leading zeros.
For queue_ids, specifies the source queue.
(Optional) [, | -] Specifies a series or range of interfaces. Enter a space
after the comma; enter a space before and after the hyphen.
(Optional) Specifies the direction of traffic to monitor. If you do not
specify a traffic direction, the source interface sends both transmitted
(Tx) and received (Rx) traffic. Only received traffic can be monitored
on additional source ports.
• Rx—Monitor received traffic.
• Tx—Monitor transmitted traffic.
• both—Monitor both received and transmitted traffic
(bidirectional).
Step 4
Switch(config)# monitor session
session_number filter vlan vlan-id [,
| -]
Limits the RSPAN source traffic to specific VLANs.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
For vlan-id, the range is 1 to 4094; do not enter leading zeros.
(Optional) Use a comma (,) to specify a series of VLANs or use a
hyphen (-) to specify a range of VLANs. Enter a space after the
comma; enter a space before and after the hyphen.
