69-12
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 69 Configuring Enhanced Object Tracking
Configuring Enhanced Object Tracking Features
Configuring a Cisco IP SLAs Monitoring Agent and Track Object
To configure network monitoring with Cisco IP SLAs, perform this task:
Configuring a Routing Policy and Default Route
• To configure a routing policy for backup static routing by using object tracking, perform the
following task. For more details about the commands in the procedure, see:
http://www.cisco.com/en/US/docs/ios/dial/configuration/guide/dia_rel_stc_rtg_bckup_support_TS
D_Island_of_Content_Chapter.html
:
Step 5
ip address dhcp
Acquires an IP address on an Ethernet interface from DHCP.
Step 6
exit
Returns to global configuration mode.
Command Purpose
Step 1
configure terminal
Enters global configuration mode.
Step 2
ip sla operation-number
Begins configuring a Cisco IP SLAs operation and enter IP SLA
configuration mode.
Step 3
icmp-echo {destination-ip-address |
destination hostname [source- ipaddr
{ip-address | hostname
source-interface interface-id
]
Configures a Cisco IP SLAs end-to-end ICMP echo response time
operation and enter IP SLAs ICMP echo configuration mode.
Step 4
timeout milliseconds
Sets the amount of time for which the operation waits for a response
from its request packet.
Step 5
frequency seconds
Sets the rate at which the operation is sent into the network.
Step 6
threshold milliseconds
Sets the rising threshold (hysteresis) that generates a reaction event
and stores history information for the operation.
Step 7
exit
Exits IP SLAs ICMP echo configuration mode.
Step 8
ip sla schedule operation-number [life
{forever | seconds}] start-time time |
pending | now | after time
] [ageout
seconds
] [recurring]
Configures the scheduling parameters for a single IP SLAs operation.
Step 9{
track object-number ip sla
operation-number {state |
reachability
}
Tracks the state of a Cisco IOS IP SLAs operation and enter tracking
configuration mode.
Step 10
end
Returns to privileged EXEC mode.
Step 11
show track object-number
Displays tracking information to verify the configuration.
Step 12
copy running-config startup-config
(Optional) Saves your entries in the configuration file.
Step 1
configure terminal
Enters global configuration mode.
Step 2
access-list access-list-number
Defines an extended IP access list. Configure any optional
characteristics.
Step 3
route-map map-tag [permit | deny]
[
sequence-number]
Enters route-map configuration mode and define conditions for
redistributing routes from one routing protocol to another.
