Cisco Catalyst 4500 Series Software Configuration Guide

49-52
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 49 Configuring 802.1X Port-Based Authentication
Configuring 802.1X Port-Based Authentication
Handle: 0xF3000061
Current Policy: POLICY_Gi2/9
Local Policies:
Template: MYACL (priority 150)
Filter-ID: TEST-ACL
Server Policies:
URL Redirect ACL: testacl
ACS ACL: xACSACLx-IP-PERMIT_ALL_TRAFFIC-51def075
Method status list:
Method State
mab Authc Success
The following command displays the contents of the Filter-Id applied on the interface:
Switch# show ip access-list interface gi6/3
deny ip host 20.20.0.2 host 155.155.155.156
deny ip host 20.20.0.2 156.100.60.0 0.0.0.255
deny tcp host 20.20.0.2 host 156.100.10.116 eq www
Guidelines for Per-User ACL and Filter-ID ACL
For per user ACL and Filter-ID ACL, the ACL source must be ANY
(permit TCP ANY host 1.1.1.1 eq 80 or permit TCP ANY host 1.1.1.1 eq 443).
Configuring a Per-User ACL and Filter-ID ACL
To configure per-user ACL and Filter-ID ACL, perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# access-list
access-list-number {deny | permit}
source [source-wildcard] [log]
Defines the default port ACL through a source address and wildcard.
The access-list-number is a decimal from 1 to 99 or 1300 to 1999.
Enter deny or permit to specify whether to deny or permit access if
conditions match.
source is the address of the network or host from which the packet is sent,
specified as follows:
• The 32-bit quantity in dotted-decimal format
• The keyword any as an abbreviation for source and source-wildcard
value of 0.0.0.0 255.255.255.255
You do not need a source-wildcard value.
• The keyword host as an abbreviation for source and source-wildcard
of source 0.0.0.0.
(Optional) Applies the source-wildcard wildcard bits to the source.
(Optional) Enters log to cause an informational logging message about the
packet that matches the entry to be sent to the console.
Step 3
Switch(config-if)# interface
interface-id
Enters interface configuration mode.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
