Cisco Catalyst 4500 Series Software Configuration Guide

17-3
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 17 Configuring VLANs, VTP, and VMPS
VLANs
• VLAN number to use when translating from one VLAN type to another
Note When the software translates from one VLAN type to another, it requires a different VLAN number for
each media type.
VLAN Configuration Guidelines and Restrictions
Follow these guidelines and restrictions when creating and modifying VLANs in your network:
• Before creating a VLAN, put the Catalyst 4500 series switch in VTP server mode or VTP
transparent mode. If the Catalyst 4500 series switch is a VTP server, you must define a VTP domain.
For information on configuring VTP, see the “VLAN Trunking Protocol” section on page 17-7.
• You cannot use the end command in VLAN database mode.
• You cannot use Ctrl-Z to exit VLAN database mode.
• If a Catalyst 4948 switch running MSTP and configured with all possible VLANs (4094) is in the
path of two HSRP peers with the timeout set below 500 ms, HSRP flaps.
Workarounds:
– Use fewer VLANs.
– Set the timers greater than 600 ms.
– Enter the no igmp snooping (globally) and access-list hardware capture mode VLAN
commands
VLAN Ranges
Note You must enable the extended system ID to use 4094 VLANs. See the “Understanding the Bridge ID”
section on page 23-2.
With Cisco IOS Release 12.2(31)SGA and later, Catalyst 4500 series switches support 4096 VLANs in
compliance with the IEEE 802.1Q standard. These VLANs are organized into three ranges: reserved,
normal, and extended.
Some of these VLANs are propagated to other switches in the network when you use the VLAN
Trunking Protocol (VTP). The extended-range VLANs are not propagated, so you must configure
extended-range VLANs manually on each network device.
Table 17-1 describes the uses for VLAN ranges.
Table 17-1 VLAN Ranges
VLANs Range Usage
Propagated
by VTP
0, 4095 Reserved For system use only. You cannot see or use these VLANs. —
1 Normal Cisco default. You cannot delete this VLAN. Yes
2–1001 Normal Used for Ethernet VLANs; you can create, use, and delete
these VLANs.
Yes
