Page #1379 background imageLoading...
Page #1379 background image
49-99
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 49 Configuring 802.1X Port-Based Authentication
Controlling Switch Access with RADIUS
Preconditions
To use the CoA interface, a session must already exist on the switch. CoA can be used to identify a session and enforce a
disconnect request. The update affects only the specified session.
CoA Request Response Code
The CoA Request response code can be used to convey a command to the switch. The supported commands are listed in
Table 49-4 on page 49-100.
Session Identification
For disconnect and CoA requests targeted at a particular session, the switch locates the session based on one or more of the
following attributes:
Calling-Station-Id (IETF attribute #31 which contains the host MAC address)
Audit-Session-Id (Cisco VSA)
Acct-Session-Id (IETF attribute #44)
Unless all session identification attributes included in the CoA message match the session, the switch returns a
Disconnect-NAK or CoA-NAK with the “Invalid Attribute Value” error-code attribute.
The packet format for a CoA Request code as defined in RFC 5176 consists of the fields: Code, Identifier, Length,
Authenticator, and Attributes in Type:Length:Value (TLV) format.
0 1 2 3
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| Code | Identifier | Length |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| |
| Authenticator |
| |
| |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
| Attributes ...
+-+-+-+-+-+-+-+-+-+-+-+-+-
The attributes field is used to carry Cisco VSAs.
502 Request Not Routable (Proxy)
503 Session Context Not Found
504 Session Context Not Removable
505 Other Proxy Processing Error
506 Resources Unavailable
507 Request Initiated
508 Multiple Session Selection Unsupported
Table 49-3 Error-Cause Values (continued)
Value Explanation
