Cisco Catalyst 4500 Series Software Configuration Guide

47-25
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 47 Configuring Private VLANs
Configuring PVLANs
Note The maximum number of unique PVLAN pairs supported by the switchport private-vlan mapping
command is 1000.
When you configure a Layer 2 Etherchannel as a PVLAN promiscuous port, note the following:
• The secondary_vlan_list parameter cannot contain spaces. It can contain multiple comma-separated
items. Each item can be a single PVLAN ID or a hyphenated range of PVLAN IDs.
• Enter a secondary_vlan_list or use the add keyword with a secondary_vlan_list to map the secondary
VLANs to the PVLAN promiscuous port.
• Use the remove keyword with a secondary_vlan_list to clear the mapping between secondary
VLANs and the PVLAN promiscuous port.
This example shows how to configure interface port channel 63 as a PVLAN promiscuous port, map it
to a PVLAN, and verify the configuration:
Switch# configure terminal
Switch(config)# interface port-channel 63
Switch(config-if)# switchport mode private-vlan promiscuous
Switch(config-if)# switchport private-vlan mapping 200 2
Switch(config-if)# end
Switch# show interfaces port-channel 63 switchport
Name:Po63
Switchport:Enabled
Administrative Mode:private-vlan promiscuous
Operational Mode:private-vlan promiscuous
Administrative Trunking Encapsulation:negotiate
Operational Trunking Encapsulation:native
Negotiation of Trunking:Off
Access Mode VLAN:1 (default)
Trunking Native Mode VLAN:1 (default)
Voice VLAN:none
Administrative Private VLAN Host Association:none
Administrative Private VLAN Promiscuous Mapping:200 (VLAN0200) 2 (VLAN0002)
Private VLAN Trunk Native VLAN:none
Administrative Private VLAN Trunk Encapsulation:dot1q
Administrative Private VLAN Trunk Normal VLANs:none
Administrative Private VLAN Trunk Private VLANs:none
Operational Private VLANs:
200 (VLAN0200) 2 (VLAN0002)
Trunking VLANs Enabled:ALL
Pruning VLANs Enabled:2-1001
Capture Mode Disabled
Capture VLANs Allowed:ALL
Step 3
Switch(config-if)# switchport mode private-vlan
{host | promiscuous | trunk promiscuous | trunk
[secondary]}
Configures a Layer 2 Etherchannel as a
PVLAN promiscuous port.
Step 4
Switch(config-if)# [no] switchport private-vlan
mapping [trunk] primary_vlan_ID
{secondary_vlan_list | add secondary_vlan_list}
(Maps the PVLAN promiscuous port to a
primary VLAN and to selected secondary
VLANs.
Step 5
Switch(config-if)# end
Exits configuration mode.
Step 6
Switch# show interface port-channel
interface-number switchport
Verifies the configuration.
Command Purpose
