Cisco Catalyst 4500 Series Software Configuration Guide

57-16
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 57 Configuring Control Plane Policing and Layer 2 Control Packet QoS
Configuring Layer 2 Control Packet QoS
The following example shows how to enable QoS for CDP packets and to apply a policer to CDP packets
arriving on interface gi3/1 and VLAN 1:
Switch# config terminal
Switch(config)# qos control-packets cdp-vtp
Switch(config)# end
Switch# show run | inc qos control-packets
qos control-packets cdp-vtp
Switch# show class-map
Class Map match-any system-control-packet-cdp-vtp (id 1)
Match access-group name system-control-packet-cdp-vtp
Create a policy map and attach it to interface gi3/1 , vlan 1
Switch# config terminal
Switch(config)# policy-map police_cdp
Switch(config-pmap)# class system-control-packet-cdp-vtp
Switch(config-pmap-c)# police 32k
Switch(config-pmap-c)# end
Switch(config)# interface gi3/1
Switch(config-if)# vlan 1
Switch(config-if-vlan-range)# service-policy in police_cdp
Switch(config-if-vlan-range)# exit
Switch(config-if)# exit
Switch(config)# exit
Switch# show policy-map interface gi3/1
GigabitEthernet3/1 vlan 1
Service-policy input: police_cdp
Class-map: system-control-packet-cdp-vtp (match-any)
0 packets
Match: access-group name system-control-packet-cdp-vtp
0 packets
police:
cir 32000 bps, bc 1500 bytes
conformed 0 packets, 0 bytes; actions:
transmit
exceeded 0 packets, 0 bytes; actions:
drop
conformed 0000 bps, exceed 0000 bps
Class-map: class-default (match-any)
0 packets
Table 57-1 Packet Type and Actionable Address Range
Type of Packet that the Feature is Enabled On Range of Address the Feature Acts On
BPDU-range 0180.C200.0000 BPDU
0180.C200.0002 OAM, LACP
0180.C200.0003 EAPOL
CDP-VTP 0100.0CCC.CCCC
SSTP 0100.0CCC.CCCD
LLDP 0180.C200.000E
