Cisco Catalyst 4500 Series Software Configuration Guide

60-26
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 60 Configuring DHCP Snooping, IP Source Guard, and IPSG for Static Hosts
Configuring IP Source Guard for Static Hosts
To stop IPSG with static hosts on an interface, use the following commands in interface configuration
submode:
Switch(config-if)# no ip verify source
Switch(config-if)# no ip device tracking max"
To enable IPSG with static hosts on a port, enter the following commands:
Switch(config)# ip device tracking ****enable IP device tracking globally
Switch(config)# ip device tracking max <n> ****set an IP device tracking maximum on int
Switch(config-if)# ip verify source tracking [port-security] ****activate IPSG on the port
Caution If you only configure the ip verify source tracking [port-security] interface configuration command
on a port without enabling IP device tracking globally or setting an IP device tracking maximum on that
interface, IPSG with static hosts will reject all the IP traffic from that interface.
This issue also applies to IPSG with static hosts on a PVLAN host port.
This example shows how to enable IPSG for static hosts with IP filters on a Layer 2 access port and to
verify the three valid IP bindings on the interface Fa4/3:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# ip device tracking
Switch(config)# interface fastEthernet 4/3
Switch(config-if)# switchport mode access
Switch(config-if)# switchport access vlan 10
Switch(config-if)# ip device tracking maximum 5
Switch(config-if)# ip verify source tracking
Switch(config-if)# end
Switch# show ip verify source
Interface Filter-type Filter-mode IP-address Mac-address Vlan
--------- ----------- ----------- --------------- ----------------- ----
Fa4/3 ip trk active 40.1.1.24 10
Fa4/3 ip trk active 40.1.1.20 10
Fa4/3 ip trk active 40.1.1.21 10
The following example shows how to enable IPSG for static hosts with IP MAC filters on a Layer 2
access port, to verify the five valid IP-MAC bindings on the interface Fa4/3, and to verify that the number
of bindings on this interface has reached the maximum limit:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# ip device tracking
Step 12
Switch# show ip verify source interface-name
Verifies the configuration.
Step 13
Switch# show ip device track all
[active | inactive] count
Verifies the configuration by displaying the IP-to-MAC
binding for a given host on the switch interface.
• all active—Displays only the active IP-to-MAC
binding entries.
• all inactive—Displays only the inactive IP-to-MAC
binding entries.
• all—Displays the active and inactive IP-to-MAC
binding entries.
Command Purpose
