Cisco Catalyst 4500 Series Software Configuration Guide

75-9
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 75 Configuring Ethernet OAM and CFM
Configuring Ethernet CFM
Step 7
ethernet cfm domain domain-name level level-id
Define a CFM domain, set the domain level, and enter
ethernet-cfm configuration mode for the domain. The
maintenance level number range is 0 to 7.
Step 8
id {mac-address domain_number | dns name |
null}
(Optional) Assign a maintenance domain identifier.
• mac-address domain_number—Enter the MAC
address and a domain number. The number can be from
0 to 65535.
• dns name—Enter a DNS name string. The name can be
a maximum of 43 characters.
• null—Assign no domain name.
Step 9
service {ma-name | ma-number | vpn-id vpn}
{vlan vlan-id [direction down] | port}
Define a customer service maintenance association (MA)
name or number or VPN ID to be associated with the
domain, a VLAN ID or port MEP, and enter
ethernet-cfm-service configuration mode.
• ma-name—a string of no more than 100 characters that
identifies the MAID.
• ma-number—a value from 0 to 65535.
• vpn-id vpn—enter a VPN ID as the ma-name.
• vlan vlan-id—VLAN range is from 1 to 4094. You
cannot use the same VLAN ID for more than one
domain at the same level.
• (Optional) direction down—specify the service
direction as down.
• port—Configure port MEP, a down MEP that is
untagged and not associated with a VLAN.
Step 10
continuity-check
Enable sending and receiving of continuity check
messages.
Step 11
continuity-check interval value
(Optional) Set the interval at which continuity check
messages are sent. The available values are 100 ms,
1 second, 10 seconds, 1 minute and 10 minutes. The default
is 10 seconds.
Note Because faster CCM rates are more CPU-intensive,
we do not recommend configuring a large number
of MEPs running at 100 ms intervals.
Step 12
continuity-check loss-threshold
threshold-value
(Optional) Set the number of continuity check messages to
be missed before declaring that an MEP is down. The range
is 2 to 255; the default is 3.
Step 13
maximum meps value
(Optional) Configure the maximum number of MEPs
allowed across the network. The range is from 1 to 65535.
The default is 100.
Command Purpose
