Cisco Catalyst 4500 Series Software Configuration Guide

15-3
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 15 Configuring Power over Ethernet
Power Management Modes
• auto—PoE interface. The supervisor engine directs the switching module to power up the interface
only if the switching module discovers the phone and the switch has enough power. You can specify
the maximum wattage that is allowed on the interface. If you do not specify a wattage, then the
switch delivers no more than the hardware-supported maximum value. This mode has no effect if
the interface is not capable of providing PoE.
• static—High priority PoE interface. The supervisor engine preallocates power to the interface, even
when nothing is connected, guaranteeing that power exists for the interface. You can specify the
maximum wattage that is allowed on the interface. If you do not specify a wattage, then the switch
preallocates the hardware-supported maximum value. If the switch does not have enough power for
the allocation, the command fails. The supervisor engine directs the switching module to power up
the interface only if the switching module discovers the powered device.
• never—Data interface only The supervisor engine never powers up the interface, even if an
unpowered phone is connected. This mode is only needed when you want to make sure power is
never applied to a PoE-capable interface.
The switch can measure the actual PoE consumption for an 802.3af-compliant PoE module, and displays
this in the show power module command.
PoE consumption cannot be measured on the WS-X4148-RJ45V PoE module. For all PoE calculations,
the PoE consumption on this module is presumed to be equal to its administrative PoE.
For more information, see the “Displaying the PoE Consumed by a Module” section on page 15-8.
For most users, the default configuration of “auto” works well, providing plug-and-play capability. No
further configuration is required. However, to make an interface higher priority or data only, or to specify
a maximum wattage, perform this task:
Command Purpose
Step 1
Switch(config)# interface {fastethernet |
gigabitethernet} slot/port
Selects the interface to configure.
Step 2
Switch(config-if)# power inline {auto [max
milli-watts] | never | static [max
milli-watts]}
The auto keyword sets the interface to automatically detect
and supply power to the powered device. it is the default
configuration.
The static keyword sets the interface to higher priority than
auto.
If necessary, use the max keyword to specify the maximum
wattage allowed on the interface (4000 to 15400 milliwatts
for most switching modules. As of Cisco IOS Release
12.2(44)SG, the WS-X4648-RJ45V+E can support up to 30
W available per-port and the WS-X4648-RJ45V-E supports
up to 20 W. For more information, see “Enhanced Power PoE
Support on the E-Series Chassis” on page 15).
Use the never keyword to disable detection and power for
the PoE capable interface.
Step 3
Switch(config-if)# end
Exits configuration mode.
Step 4
Switch# show power inline {fastethernet |
gigabitethernet} slot/port
Displays the PoE state for the switch.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
