Cisco Catalyst 4500 Series Software Configuration Guide

17-15
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 17 Configuring VLANs, VTP, and VMPS
VLAN Trunking Protocol
Enabling VTP Pruning
To enable VTP pruning in the management domain, perform this task:
This example shows one way to enable VTP pruning in the management domain:
Switch# configure terminal
Switch(config)# vtp pruning
Pruning switched ON
This example shows how to enable VTP pruning in the management domain with any release:
Switch# vtp pruning
Pruning switched ON
This example shows how to verify the configuration:
Switch# show vtp status | include Pruning
VTP Pruning Mode: Enabled
Switch#
For information about configuring prune eligibility, see the “Understanding VTP Pruning” section on
page 17-10.
Enabling the VTP Version Number
VTP version 2 is disabled by default on VTP version-2-capable network devices. When you enable VTP
version 2 on a network device, every VTP version-2-capable network device in the VTP domain enables
version 2.
Caution VTP version 1 and VTP version 2 are not interoperable on network devices in the same VTP domain.
Every network device in the VTP domain must use the same VTP version. Do not enable VTP version 2
unless every network device in the VTP domain supports version 2.
Note In a Token Ring environment, you must enable VTP version 2 or VTP version 3 for Token Ring VLAN
switching to function properly on devices that support Token Ring interfaces.
To enable the VTP version, perform this task:
Command Purpose
Step 1
Switch(config)# vtp pruning
Enables VTP pruning in the management domain.
Step 2
Switch# show vtp status | include pruning
(Optional) Verifies the configuration.
Command Purpose
Step 1
Switch(config)# vtp version {1 | 2 | 3}
Enables the VTP version.
Step 2
Switch# show vtp status | include {v1 | v2 | v3}
(Optional) Verifies the configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
