Chapter 25 Configuring Resilient Ethernet Protocol
Configuring REP
To configure the REP administrative VLAN, perform this task:
This example shows how to configure the administrative VLAN as VLAN 100 and verify the
configuration by entering the show interface rep detail command on one of the REP interfaces:
Switch# configure terminal
Switch (config)# rep admin vlan 100
Switch (config)# end
Switch# show interface gigabitethernet1/1 rep detail
GigabitEthernet1/1 REP enabled
Segment-id: 2 (Edge)
PortID: 00010019E7144680
Preferred flag: No
Operational Link Status: TWO_WAY
Current Key: 0002001121A2D5800E4D
Port Role: Open
Blocked Vlan: <empty>
Admin-vlan: 100
Preempt Delay Timer: disabled
Load-balancing block port: none
Load-balancing block vlan: none
STCN Propagate to: none
LSL PDU rx: 3322, tx: 1722
HFL PDU rx: 32, tx: 5
BPA TLV rx: 16849, tx: 508
BPA (STCN, LSL) TLV rx: 0, tx: 0
BPA (STCN, HFL) TLV rx: 0, tx: 0
EPA-ELECTION TLV rx: 118, tx: 118
EPA-COMMAND TLV rx: 0, tx: 0
EPA-INFO TLV rx: 4214, tx: 4190
This example shows how to create an administrative VLAN per segment. Here VLAN ID 2 is configured
as the administrative VLAN only for REP segment 2. All remaining segments have VLAN 1 as the
administrative VLAN.
Switch# configure terminal
Switch (config)# rep admin vlan 2 segment 2
Switch (config)# end
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# rep admin vlan vlan-id
Specifies the administrative VLAN ID for the entire
domain (all segments). The VLAN ID range is 2 to 4094.
The default is VLAN 1.
To specify the administrative VLAN ID per segment,
enter the rep admin vlan vlan-id segment segment-id
global configuration command.
To set the admin VLAN ID to 1, enter the no rep admin
vlan global configuration command.
Step 3
Switch(config)# end
Returns to privileged EXEC mode.
Step 4
Switch# show interface [interface-id] rep detail
Verifies configuration on the specified REP interface.
Step 5
Switch# copy running-config startup config
(Optional) Saves your entries in the switch startup
configuration file.
