Cisco Catalyst 4500 Series Software Configuration Guide

38-19
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 38 Configuring IP Multicast
Configuring IP Multicast Routing
Step 9
Switch(config)# ip pim send-rp-announce
{interface-type interface-number | ip-address}
scope ttl-value [group-list access-list]
[interval seconds] [bidir]
Sends RP announcements out all PIM-enabled interfaces.
• Perform this step on the RP router only.
• Use the interface-type and interface-number arguments
to define which IP address is to be used as the RP
address.
• Use the ip-address argument to specify a directly
connected IP address as the RP address.
Note If the ip-address argument is configured for this
command, the RP-announce message is sourced by
the interface to which this IP address is connected
(that is, the source address in the IP header of the
RP-announce message is the IP address of that
interface).
• This example shows that the interface is enabled with a
maximum of 31 hops. The IP address by which the
router wants to be identified as RP is the IP address
associated with loopback interface 0. Access list 5
describes the groups for which this router serves as RP.
Step 10
Switch(config)# ip pim send-rp-discovery
[interface-type interface-number] scope
ttl-value [interval seconds]
Configures the router to be an RP mapping agent.
• Perform this step on the RP router only.
• Use the optional interface-type and interface-number
arguments to define which IP address is to be used as
the source address of the RP mapping agent.
• Use the scope keyword and ttl-value argument to
specify the Time-to-Live (TTL) value in the IP header
of Auto-RP discovery messages.
• Use the optional interval keyword and seconds
argument to specify the interval at which Auto-RP
discovery messages are sent.
Note Lowering the interval at which Auto-RP discovery
messages are sent from the default value of 60
seconds results in more frequent floodings of the
group-to-RP mappings. In some network
environments, the disadvantages of lowering the
interval (more control packet overhead) may
outweigh the advantages (more frequent
Requirementsgroup-to-RP mapping updates).
• The example shows limiting the Auto-RP discovery
messages to 31 hops on loopback interface 1.
Command or Action Purpose

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
