Cisco Catalyst 4500 Series Software Configuration Guide

5-49
Catalyst 4500 Series Switch, Cisco IOS Software Configuration Guide - Cisco IOS XE 3.9.xE and IOS 15.2(5)Ex
Chapter 5 Configuring Virtual Switching Systems
Configuring a VSS
Switch(config-if)# ip address 172.32.52.10 255.255.255.0
Switch(config-if)# end
This example shows how to verify the configuration of port channel interface 1:
Switch# show running-config interface port-channel 1
Building configuration...
Current configuration:
!
interface Port-channel1
ip address 172.32.52.10 255.255.255.0
end
Switch#
Configuring Physical Interfaces as Layer 3 EtherChannels
To configure physical interfaces as Layer 3 EtherChannels, perform this task for each interface:
This example shows how to configure Gigabit Ethernet interfaces 1/3/26 and 2/2/26 into port channel 1
with PAgP mode desirable:
Switch(config)# conf terminal
Switch(config)# int gigabitEthernet 1/3/26
Switch(config-if)# no switchport
Switch(config-if)# no ip address
Switch(config-if)# channel-group 1 mode desirable
Switch(config-if)# exit
Switch(config)# int gigabitEthernet 2/2/6
Switch(config-if)# no switchport
Command Purpose
Step 1
Switch(config)# interface {fastethernet |
gigabitethernet | tengigabitethernet} slot/port
Selects a physical interface to configure.
Step 2
Switch(config-if)# no switchport
Makes this a Layer 3 routed port.
Step 3
Switch(config-if)# no ip address
Ensures that no IP address is assigned to the physical
interface.
Step 4
Switch(config-if)# channel-group port_channel_number
mode {active | on | auto | passive | desirable}
Configures the interface in a port channel and
specifies the PAgP or LACP mode.
If you use PAgP, enter the keywords auto or
desirable.
If you use LACP, enter the keywords active or
passive.
Step 5
Switch(config-if)# end
Exits configuration mode.
Step 6
Switch# show running-config interface port-channel
port_channel_number
Switch# show running-config interface {fastethernet
| gigabitethernet | tengigabitethernet} slot/port
Switch# show interfaces {fastethernet |
gigabitethernet | tengigabitethernet} slot/port
etherchannel
Switch# show etherchannel 1 port-channel
Verifies the configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
