7. SYSTEM SETTINGS
129
• Division
Selects the division transmission system when SDI System is 4K 3G Dual Link.
If you select 2 Sample Interleaved when Psf format is in use, the instrument will not
operate properly.
Square / 2 Sample Interleave
• i/PsF Select
The instrument cannot detect the following formats if the payload ID is not in use or is not
embedded. In such a case, select whether to use interlace or segmented frame for
displaying.
This cannot be selected when SDI System is 4K.
• 1080/60I and 1080/30PsF
• 1080/59.94I and 1080/29.97PsF
• 1080/50I and 1080/25PsF
Interlace / Segmented Frame(PsF)
• Color System
Select the color system of the input signal.
YCbCr 422 / YCbCr 444 / RGB 444 / XYZ 444
• Pixel Depth
Select the quantization of the input signal.
10bit / 12bit
