Leader LV5300A - TELNET Commands

19. Network Control
441
19.2.3 TELNET Commands
TELNET commands follow the instrument or the option menu structure. Some of the
descriptions do not apply depending on the installed options or the current settings.
• INPUT KEY
r/w
Limitation
Command
Parameter
-
INPUT
SINGLE / SIMUL / ?
-
INPUT:SINGLE_A
ON / ? (Return value:ON(Channel
A selected) / OFF(not selected))
SD/HD/3G-A/3G-B-DL setting, Select the
display channel in single input mode.
-
INPUT:SINGLE_B
ON / ? (Return value:ON(Channel
B selected) / OFF(not selected))
-
INPUT:SIMUL_A
OFF / ON / ? (Return
value:Channel A display on/off)
SD/HD/3G-A/3G-B-DL setting, Select the
display channel in simul mode.
-
INPUT:SIMUL_B
OFF / ON / ? (Return
value:Channel B display on/off)
-
INPUT:12G_A
ON / ? (Return value:ON(Channel
A selected) / OFF(not selected))
4K 12G setting, Select the display channel.
-
INPUT:SINGLE_DUA
L_AB
ON / ? (Return value: Channel A-B
pair display on/off(not selected))
4K 3G Dual Link setting, Select the display
channel in single input mode.
-
INPUT:OPERATE
COM / INDIVIDUAL / ?
-
INPUT:6G_A
ON / ? (Return value:ON(Channel
A selected) / OFF(not selected))
4K 6G setting, Select the display channel.
• EXT KEY
r/w
Limitation
Command
Parameter
-
EXT
INT / EXT / ?
• CAP KEY
r/w
Limitation
Command
Parameter
WO
CAP:REFRESH
None
-
CAP:DISPLAY
REAL / HOLD / BOTH / ?
-
CAP:FILE:BMP
OFF / ON / ?
-
CAP:FILE:BSG
OFF / ON / ?
WO
CAP:STORE
None
WO
MAKE
CAP_BMP / CAP_BSG / LOG / DUMP (*1) /
SCTE104_TEXT / SCTE104_SPLICE
* File make command. Use FTP to retrieve
created files.
*1 If you want to create an event log, or data
dump file, the corresponding measurement
screen must be displayed on the screen.
• PRESET KEY
r/w
Limitation
Command
Parameter
WO
RCLL
1 to 60
• MULTI KEY
r/w
Limitation
Command
Parameter
-
MULTI
OFF / ON / ?
WO
USER:LYT
USER1/ USER2 / USER3 / USER4 / USER5 / USER6
