19. Network Control
442
• SYS KEY
r/w
Limitation
Command
Parameter
-
SYS:LCD:BACKLIGHT
1 to 32 / ?
WO
SYS:LCD:ON
None
WO
SYS:LCD:OFF
None
WO
SYS:INITIALIZE:PARAM
None
WO
SYS:INITIALIZE:LAYOUT
None
WO
SYS:INITIALIZE:OPERATE
None
WO
SYS:INITIALIZE:ALL
None
-
SYS:SDI:SYSTEM
4K_12G / 4K_6G / 4K_3G_DLINK / SINGLE_LINK
/ ?
* Correspondence between parameters and
settings
4K_12G : 4K 12G
4K_6G : 4K 6G
4K_3G_DLINK : 4K 3G Dual Link
SINGLE_LINK : SD/HD/3G-A/3G-B-DL
-
SYS:SDI:COLORIMETRY
PAYLOAD_ID / BT709 / BT2020 / DCI / ?
-
SYS:XYZ_GAMMA
BOTTOM_ZERO / DCI / ?
-
SYS:HDR:MODE_A
OFF / HLG / PQ / SLOG3 / CLOG / LOGC / ?
-
SYS:HDR:MODE_B
OFF / HLG / PQ / SLOG3 / CLOG / LOGC / ?
-
SYS:HDR:GAMMA_A
OFF / ON / ?
-
SYS:HDR:GAMMA_B
OFF / ON / ?
-
SYS:HDR:HLG_SCALE_A
1200P / 100P / ?
-
SYS:HDR:HLG_SCALE_B
1200P / 100P / ?
-
SYS:HDR:RANGE_A
NARROW / FULL / ?
-
SYS:HDR:RANGE_B
NARROW / FULL / ?
-
SYS:HDR:EI_A
EI200 / EI400 / EI800 / EI1600 / ?
-
SYS:HDR:EI_B
EI200 / EI400 / EI800 / EI1600 / ?
-
SYS:HDR:DETECT_PAYLOAD_A
OFF / ON / ?
-
SYS:HDR:DETECT_PAYLOAD_B
OFF / ON / ?
-
SYS:HDR:REF_LV_HLG_A
50P / 75P / ?
-
SYS:HDR:REF_LV_HLG_B
50P / 75P / ?
-
SYS:HDR:REF_LV_PQ_A
51P / 58P / ?
-
SYS:HDR:REF_LV_PQ_B
51P / 58P / ?
• WFM KEY
r/w
Limitation
Command
Parameter
WO
WFM
None
-
WFM:MODE
OVERLAY / PARADE / ?
-
WFM:MODE:YCBCR:Y
ON / OFF / ?
-
WFM:MODE:YCBCR:CB
ON / OFF / ?
-
WFM:MODE:YCBCR:CR
ON / OFF / ?
-
WFM:MODE:GBR:G
ON / OFF / ?
-
WFM:MODE:GBR:B
ON / OFF / ?
-
WFM:MODE:GBR:R
ON / OFF / ?
-
WFM:MODE:RGB:R
ON / OFF / ?
-
WFM:MODE:RGB:G
ON / OFF / ?
-
WFM:MODE:RGB:B
ON / OFF / ?
-
WFM:MODE:XYZ:X
ON / OFF / ?
-
WFM:MODE:XYZ:Y
ON / OFF / ?
-
WFM:MODE:XYZ:Z
ON / OFF / ?
-
WFM:INTEN
-128 to 127 / ?
