Leader LV5300A - Selecting the X-Axis Measurement Unit; Moving the Cursors; Turning the Cursor Value Display on and off

10. Video Signal Waveform Display
202
10.6.4 Selecting the X-Axis Measurement Unit
When F•2 XY SELECT is set to X, to select the X-axis cursor measurement unit, follow the
procedure below.
Procedure
WFM → F•4 CURSOR → F•3 X UNIT: sec / Hz
Settings
sec: The measurement unit is seconds.
Hz: The measurement unit is frequency, with the length of one period set to
the distance between the two cursors.
10.6.5 Moving the Cursors
To move a cursor, follow the procedure shown below to select a cursor. Then, move the
cursor by turning the function dial (F•D). Triangles appear on both ends of the selected
cursor.
You can also select a cursor by pressing the function dial (F•D). Each time you press the
function dial (F•D), the selected cursor switches from REF, to DELTA, to TRACK, and then
back to REF.
Procedure
WFM → F•4 CURSOR → F•4 FD VALUE: REF / DELTA / TRACK
10.6.6 Turning the Cursor Value Display On and Off
To display cursor values, follow the procedure shown below (except when F•3 Y UNIT is set
to R%).
The display unit is the unit specified with F•3 Y UNIT or F•3 X UNIT.
If F•1 CURSOR is set to BOTH, the value is displayed on the cursor selected with F•2 XY
SELECT.
Procedure
WFM → F•4 CURSOR → F•5 CURSOR VALUE: ON / OFF
