17. Eye Pattern Display (LV5300/LV5300A/LV7300-SER02)
426
17.10.11 Resetting Cursors
To reset the cursor positions, follow the procedure below.
Procedure
EYE → F•4 CURSOR → F•6 CURSOR RESET
17.10.12 Selecting the Display Mode
To select the jitter display mode, follow the procedure below.
If the eye pattern and jitter are displayed simultaneously, the setting specified here also
applies to the eye pattern.
Procedure
EYE → F•5 TRIGGER: RUN / STOP
Settings
RUN: The input signal is automatically updated and displayed.
STOP: The input signal is displayed statically. This is convenient for cursor
measurement.
Even if STOP is selected, if you change the measurement conditions, such
as switching to eye pattern, the mode switches to RUN.
17.10.13 Selecting the 2-Screen Display Mode
To select the jitter’s 2-screen display mode, follow the procedure below.
Procedure
EYE → F•7 DISPLAY MODE: SINGLE / DUAL
Settings
SINGLE: Displays the jitter waveform of the selected filter in a single screen
DUAL: Displays the timing jitter and the jitter waveform of the selected filter in
two screens
