Leader LV5300A - Command Mode

18. Remote Control
433
18.3 Command Mode
This section describes the control method when Mode on the SYS menu is set to Command.
• Pinout
Table 18-4 Pinout
Pin No.
Name
I/O (*1)
Description
1
OPEN
-
Open (*2)
2
/F1
I
Function 1
3
/F2
I
Function 2
4
/F3
I
Function 3
5
/F4
I
Function 4
6
/F5
I
Function 5
7
/F6
I
Function 6
8
/F7
I
Function 7
9
/F8
I
Function 8
10
CMD1
I
Command 1
11
CMD2
I
Command 2
12
CMD3
I
Command 3
13
/STR
I
Strobe
14
ALARM
O
Alarm output
15
GND
-
Ground
*1 Is (inputs) are all pulled up to +3.3 V but can also receive +5 V.
*2 Do not connect anything.
The functions that can be assigned to pins 2 to 9 of the remote connector vary depending
on the setting specified by pins 10 to 12 as follows.
Table 18-5 Command mode functions
Pin No.
Name
Function
Preset
recall (Bit)
Preset
recall (Binary)
Switch the display channel
Tally display (SER27)
10
CMD1
H
L
L
H
11
CMD2
H
H
L
H
12
CMD3
H
H
H
L
2
/F1
Recall 1
Recall 1 (LSB)
Selects channel A
Channel A tally 1 display
3
/F2
Recall 2
Recall 2
Selects channel B
Channel A tally 2 display
4
/F3
Recall 3
Recall 3
-
Channel B tally 1 display
5
/F4
Recall 4
Recall 4
-
Channel B tally 2 display
6
/F5
Recall 5
Recall 5
-
-
7
/F6
Recall 6
Recall 6 (MSB)
-
-
8
/F7
Recall 7
-
-
-
9
/F8
Recall 8
-
-
-
