13. Picture Screen
290
13.9 Configuring the Line Selection Settings
To configure the line selection settings, press F•5 LINE SELECT on the PIC menu.
This menu item does not appear when PICTURE MODE is set to a value other than FIT.
[See also] PICTURE MODE → 13.1, “Selecting the Display Mode”
PIC → F•5 LINE SELECT →
Figure 13-34 LINE SELECT menu
13.9.1 Turning Line Selection On and Off
To display a marker at the selected line, follow the procedure below. You can use the
function dial (F•D) to select a line. The number of the selected line appears in the upper left
of the screen.
Changing this setting will also change the video-signal-waveform-display and vector-display
line selection settings.
Procedure
PIC → F•5 LINE SELECT → F•1 LINE SELECT: ON / OFF
LINE SELECT = ON
Figure 13-35 Turning line selection on and off
