17. Eye Pattern Display (LV5300/LV5300A/LV7300-SER02)
422
17.10.1 Selecting the Magnification
To select the jitter display magnification, follow the procedure below.
Procedure
EYE → F•2 GAIN/FILTER/SWEEP → F•2 GAIN MAG
: X1 / X2 / X8 (for formats other than 12G)
: X1 / X2 / X4 / X16 (for 12G)
17.10.2 Selecting the Filter
To select the filter that is used during jitter measurement, follow the procedure below. The
selected filter is indicated at the bottom of the display.
If you change this setting, the filter that you selected for the eye pattern display also
changes.
[See also] 17.9.2, “Selecting the Filter”
Procedure
EYE → F•2 GAIN/FILTER/SWEEP → F•3 FILTER: 100kHz / 1kHz / 100Hz / 10Hz / TIMING /
ALIGNMENT
17.10.3 Selecting the Sweep Time
To select the sweep time, follow the procedure below.
Procedure
EYE → F•2 GAIN/FILTER/SWEEP → F•4 SWEEP: 1H / 2H / 1V / 2V
Settings
1H: The jitter from a period of one line is shown.
2H: The jitter from a period of two lines is shown.
1V: When the input signal is interlace or segmented frame, the jitter from a
period of one field is shown. When the input signal is progressive, the
jitter from a period of one frame is shown.
2V: When the input signal is interlace or segmented frame, the jitter from a
period of one frame is shown. When the input signal is progressive, the
jitter from a period of two frames is shown.
This option cannot be selected when the input signal is progressive.
