16. Status Display
385
16.9.13 Displaying Program Data
To display whether program description packets that are specified by the ATSC A/65
standard are present, follow the procedure below. For each descriptor, if its ID is present,
“DETECT” is displayed; if its ID is not present, “MISSING” is displayed.
Procedure
STATUS → F•4 ANC PACKET → F•1 PACKET ANALYSIS → F•4 V-ANC → F•2 SMPTE
→ F•3 PROGRAM
Figure 16-33 Program data display
• Selecting the Content to Display
You can select the displayed content using F•5 LINK when the input signal is multi link
and F•5 SUB when the input signal is 6G or 12G.
