7. SYSTEM SETTINGS
149
• Server IP Address
• Time Zone Adjust
When the SNTP client function is set to ON, enter the NTP server IP address in Server IP
Address and the time adjustment value in Time Zone Adjust.
7.2.8 Configuring the Server
Use Server on the NETWORK tab to configure the TELNE, FTP, and HTTP.
The settings that you specify here will not be initialized even if you initialize the instrument.
In addition, they are not recorded to presets.
SYS → F•2 SYSTEM SETUP → F•2 PREV TAB or F•3 NEXT TAB →
Figure 7-17 NETWORK tab
• Telnet
Select whether to enable the TELNET server feature and the LV7290 REMOTE
CONTROLLER.
You cannot use TELNET and the LV7290 at the same time.
Off / On / LV7290
• FTP Server
Select whether to enable the FTP server function.
Off / On
• HTTP Server
Select whether to enable the HTTP server feature.
Off / On
