12. CIE Chromaticity Diagram Display (SER22)
246
12.2.3 Turning Clipping On and Off
To turn clipping on and off, follow the procedure below.
Procedure
VECT → F•3 CIE DIAGRAM SETTING → F•3 CLIP: ON / OFF
Settings
ON: Negative values of the input signal are clipped to zero.
OFF: Negative values of the input signal are displayed according to BT.1361.
12.2.4 Turning the Filter On and Off
To turn the filter on and off, follow the procedure below.
When set to ON, data is averaged every two pixels and displayed.
Procedure
VECT → F•3 CIE DIAGRAM SETTING → F•4 FILTER: ON / OFF
12.2.5 Setting the Gamma Value
To set the gamma value, follow the procedure below.
Procedure
VECT → F•3 CIE DIAGRAM SETTING → F•5 MANUAL SETUP
→ F•1 MANUAL SETUP: ON / OFF
→ F•2 COLORIMETRY: BT.601(525) / BT.601(625) / BT.709 / DCI / BT.2020
→ F•5 GAMMA SETUP: 1.50 - 2.20 - 3.00
Settings
ON: The colorimetry set using F•2 COLORIMETRY and the gamma value set
with F•5 GAMMA SETUP are used. However, this is not applied to the
video-signal-waveform, vector, or picture display.
The gamma calculation expression is (input signal level)^(gamma value).
Negative input signal values are clipped to zero, regardless of whether
F•3 CLIP is set to on or off.
OFF: The colorimetry standard selected on the SYS menu is used.
