14. HDR Display (SER23)
302
14.1.4 Cursor Display
During cursor measurement, to display measured values for HDR signals, follow the
procedure below.
The unit of measurement is % when on the HDR tab, HDR Mode is HLG or S-Log3 and
SYSTEM GAMMA is OFF and Nits when HDR Mode is HLG or S-Log3 and SYSTEM GAMMA is
ON or when HDR Mode is PQ.
Procedure
WFM → F•4 CURSOR → F•3 Y UNIT: HDR
Y UNIT = HDR
Figure 14-4 Cursor display (HDR Mode = PQ)
