3. SPECIFICATIONS
17
3.3.4 SDI Output Connector (SER01/SER02/SER24/SER28)
Connector Type BNC
Number of Output Connectors
2 (SDI INPUT 1, 2)
Output Impedance 75Ω
Output Return Loss
5 MHz to 1.485 GHz -15 dB or more
1.485 to 2.970 GHz -10 dB or more
2.970 to 5.940 GHz -7 dB or more (SDI OUTPUT 1)
5.940 to 11.880 GHz -4 dB or more (SDI OUTPUT 1)
Output Voltage 800 mVp-p ± 10 % (into 75 Ω)
Output Signal (LV5300/LV5300A/LV5350)
Reclocked signal of SDI input (*1), TSG output, SDI monitor
output
SDI OUTPUT 1 Reclock output of SDI INPUT 1 or selected reclock output of
SDI INPUT 1/2
SDI OUTPUT 2 Reclock output of SDI INPUT 2 (*1), SDI monitor output, or
TSG output
SDI Monitor Output Signal
Outputs the LCD screen in HD, 3G-A, or 3G-B-DL.
SDI Monitor Output Format
Color System
Quantization
Frame (Field) Frequency/Scanning
Supported Standard
YC
B
C
R
4:2:2
10bit
1920×1080
60/59.94/50 /I
24/23.98 /PsF (*2)
SMPTE ST 274
60/59.94/50/48/47.95 /P
SDI Monitor Output Synchronization
Synchronizes to the refresh rate of the LCD (free run)
Output Signal (LV7300) Reclocked signal of SDI input (*1), TSG output
SDI OUTPUT 1 Reclock output of SDI INPUT 1 or selected reclock output of
SDI INPUT 1/2
SDI OUTPUT 2 Reclock output of SDI INPUT 2 (*3) or TSG output
*1 When SDI system setting is 2K SD/HD/3G-B-DL/3G-A and input signal is 6G-SDI, reclock output is
not possible.
*2 Equivalent to 48I when the SDI input is 48P.
*3 This is not output when the input is 6G-SDI, 12G-SDI.
