10. Video Signal Waveform Display
195
H SWEEP = 2H
Figure 10-17 Selecting the line display format
10.5.3 Selecting the Field Display Format
When F•1 SWEEP is set to V, to select the sweep time, follow the procedure below.
Procedure
WFM → F•3 SWEEP → F•2 V SWEEP: 1V / 2V
Settings
1V: One field is displayed.
2V: One frame is displayed. This option cannot be selected when the input
signal is progressive.
V SWEEP = 1V
